When designing a leak-free instrumentation system, one of the first steps to ensuring safety and reliability is to select the right tubing for the intended application. No system integrity is complete without this critical link and its compatibility with the rest of the components. In this post we list four key parameters to consider when selecting quality instrument tube for use with Parker A-LOK® and CPITM tube fittings.
Parker’s instrument tube fittings have been designed to work in a wide variety of applications that demand the utmost in product performance. Their compatibility with selected tubing is critical for providing consistently high-level of reliability.
- Material compatibility
The most important consideration in the selection of suitable tubing for any application is the compatibility of the tubing material with the media to be contained. Table 1 lists common materials and their associated general applications. It also lists the minimum and maximum operating temperatures for the various tubing materials.
In addition, Parker instrument fittings are designed to work on like materials. Stainless steel fittings should be used only with stainless steel tubing, 6MO fittings with 6MO tubing, etc. The practice of mixing materials is strongly discouraged.
- Tubing hardness
The key is to select tube material which is softer than the tube fitting material. For example, Stainless Steel tubing should be specified as Rb 80 or less hardness value. Parker A-LOK® / CPI™ Tube Fittings have, however, been tested on tubing up to Rb 90 hardness level with excellent performance.
- Wall thickness
Proper wall thickness is necessary to accommodate accepted safety factors relative to desired working pressures. Tube tables published in Parker’s literature, list the tube Outside Diameter (OD) sizes and Wall Thickness combinations per material for safe use with Parker A-LOK® and CPITM tube fittings. Do not use tube with wall thickness values which fall outside of the table ranges.
All working pressures are calculated following the recommendations contained within the ASME B31.3 Chemical Plant and Petroleum Refinery Piping Code and ASME B31.1, Power Piping. All calculations are confirmed via rigorous and extensive testing procedures at our Parker RD Laboratories. Each calculation utilises an allowable stress figure that incorporates a 4:1 factor of safety.
All testing is carried out to replicate actual working conditions where possible. Parker does not ‘support’ tube to facilitate failure at certain points as this does not truly represent the forces that our products would see in ‘real-time’ applications.
Not all manufacturers support their assemblies’ pressure rating claims with extensive testing. In these cases it is important to understand the implications associated with using unverified recommendations.
